Glass Crafters Inc.

Frameless Beveled Mirrored Cabinet

Offering the same utility and function as the flat series, the frameless 3/4" bevel cabinet series adds a crisp flair to the mirror. Utilizing the strength of 4mm mirror, our glass experts craft a precise 3/4" beveled edge on the mirror. Personalize your design without sacrificing function. The 3/4" Frameless Bevel offers the same options as the Flat Mirror series.

List Price Starting At $662.00

Features & Benefits

  • Lifetime warranty on mechanical parts
  • Rust-proof satin anodized aluminum construction
  • Precisely mitered door frames, eliminating the need for plastic corners
  • Soft-close, Blumotion® cushion softly and effortlessly adjusts to the closing force of the door eliminating the need for unsightly vinyls or seals
  • Installer friendly, award-winning, Austrian snap-on Blum® hinges with three-way adjustment, door opens to 170° or 130° with limit clips
  • Mirrored cabinet, door mirrored inside and out
  • Three widths available: 16", 20", 24"
  • Three heights available: 24", 30" & 36"
  • Two cabinet depths: 4" & 6"
  • Mirrored door flat hi-polished edge or 3/4" beveled upgrade
  • Cabinets available recessed, semi-recessed or surface mounted
  • Semi-recessed or surface mount side mirror kits available
  • Snap-fit adjustable 5/16" clear glass shelves with 2" spacing
  • Left or right universal hinge for non-electric option cabinets
  • Cabinets can be combined horizontally or vertically
  • Includes 3X magnification mirror and storage accessories
SIZE CHART
Video
DETAIL
TECHNICAL
MAINTENANCE

Available Sizes

ModelOverall DimensionRough OpeningSide Mirror Kit - Semi Recess/Surface Mount
GC1624-4-SC-FM15" x 24"14 3/8" x 23 3/8"SMK4-24
GC1630-4-SC-FM15" x 30"14 3/8" x 29 3/8"SMK4-30
GC1630-6-SC-FM15" x 30"14 3/8" x 29 3/8"SRMK2-30 / SMK6-30
GC1636-4-SC-FM15" x 36"14 3/8" x 35 3/8"SMK4-36
GC1636-6-SC-FM15" x 36"14 3/8" x 35 3/8"SRMK2-36 / SMK6-36
GC2030-4-SC-FM19" x 30"18 3/8" x 29 3/8"SMK4-30
GC2030-6-SC-FM19" x 30"18 3/8" x 29 3/8"SRMK2-30 / SMK6-30
GC2036-4-SC-FM19" x 36"18 3/8" x 35 3/8"SMK4-36
GC2036-6-SC-FM19" x 36"18 3/8" x 35 3/8"SRMK2-36 / SMK6-36
GC2430-4-SC-FM23" x 30"22 3/8" x 29 3/8"SMK4-30
GC2430-6-SC-FM23" x 30"22 3/8" x 29 3/8"SRMK2-30 / SMK6-30
GC2436-4-SC-FM23" x 36"22 3/8" x 35 3/8"SMK4-36
GC2436-6-SC-FM23" x 36"22 3/8" x 35 3/8"SRMK2-36 / SMK6-36

Detail

Maintenance

We realize that the marketplace offers many choices and we thank you for selecting GlassCrafters for your Mirrored Cabinet needs. The ensuing care instructions should be followed to ensure the longer life and beauty of your Mirrored Cabinet or Decorative Wall Mirror. For cleaning the mirror, we recommend using ammonia free Sprayway brand glass cleaner, which is available at a variety of retail outlets.

Never use abrasive cleaners or cleaners containing ammonia. This may cause chemical damage to the mirror and void the warranty.

Note: abrasive cleaning agents such as denatured alcohol will damage the lacquer finish on GlassCrafters Inc.’s satin brass frames and void the product warranty.
